– Our patent split-lobe microwave communication parabolic antenna for large diameter, which can save packaging and transportation costs greatly without any quality compromised；
– High Performance ETSI Class 3 Parabolic Antennas with exceptional front/back ratio – Excellent performance for a wide range of applications；
– Simple Assembly – Minimal required assembly simplifies installation on site and guarantees “factory-tested” quality；
| Antenna Model | Antenna Size(m) | Frequency (GHz) | Gain(dBi) | 3dB BW (degs) | XPD (dB) | VSWR | F/B radio (dB) | ISO | ||
| Low | Mid | Top | ||||||||
| CM18U6WD | 1.8 | 5.925-7.125 | 38.4 | 39.4 | 39.8 | 1.8 | 30 | 1.3 | 65 | 35 |
| CM18U7WD | 1.8 | 7.125-8.5 | 40.0 | 40.8 | 41.5 | 1.5 | 30 | 1.3 | 66 | 35 |
| CM18U10WD | 1.8 | 10.125-11.7 | 43.0 | 43.7 | 44.3 | 1.1 | 30 | 1.3 | 71 | 35 |
| CM18U13D | 1.8 | 12.75-13.25 | 45.0 | 45.2 | 45.3 | 0.9 | 30 | 1.3 | 70 | 35 |
| CM18U15D | 1.8 | 14.4-15.35 | 46.1 | 46.3 | 46.6 | 0.8 | 30 | 1.3 | 71 | 35 |
| CM18U18D | 1.8 | 17.7-19.7 | 47.9 | 48.3 | 48.8 | 0.6 | 30 | 1.3 | 73 | 35 |
| CM18U23D | 1.8 | 21.2-23.6 | 49.4 | 49.9 | 50.4 | 0.5 | 30 | 1.3 | 75 | 35 |
